| 下行参数 | 解调方式 | 64/256QAM |
|---|
| 传输速率 | Up to 440 Mbps (8 channels*55.2Mbps) |
|---|
| 频率范围 | 91 to 998MHz (Center) DOCSIS 108 to 1002MHz (Edge) Euro-DOCSIS |
|---|
| 信道带宽 | 6MHz (DOCSIS) 8MHz (Euro-DOCSIS) |
|---|
| 接收电平 | DOCSIS -15dBmV to +15dBmV Euro-DOCSIS -17dBmV to +13dBmV(64QAM) -13dBmVto +17dBmV(256QAM) |
|---|
| 反射损耗 | ≥8 dB (91~857 MHz) (Center) DOCSIS ≥ 8 dB (108~862 MHz) (Edge) Euro-DOCSIS |
|---|
|
| 上行参数 | 调制方式 | QPSK,8QAM,16QAM,32QAM, 64QAM, 128QAM |
|---|
| 传输速率 | 120 Mbps (30.72 Mbps x 4 channels) |
|---|
| 频率范围 | 5 to 42MHz (edge to edge) DOCSIS 5 to 65MHz(edge to edge) Euro-DOCSIS |
|---|
| 信道带宽 | 0.2, 0.4, 0.8, 1.6,3.2,6.4MHz |
|---|
| 发射电平 | A-TDMA: +8 to +54 dBmV (32QAM, 64QAM), +8 to +58 dBmV (QPSK) (Output level of CM can automatically controlled by CMTS through power ranging function), Step: 1dB |
|---|
(Output level of CM can automaticallycontrolled by CMTS through power rangingfunction), Step: 1dB |
| 反射损耗 | ≥ 8 dB (5-42 MHz) DOCSIS ≥ 8 dB (5-65 MHz) Euro-DOCSIS |
|---|
|
| 无线协议 | 802.11n/g/b |
|---|
| 传输速率 | 300 Mbps(2 x 2 MIMO) |
|---|
| 频率范围 | 2.4 to 2.484 GHz |
|---|
| 发射电平 | 17 dBm |
|---|
| 外置天线 | 2 x adjustable position external antennas (5 dBi) |
|---|
|
| 功能业务 | • IPv4 and IPv6 |
|---|
| • 32 (32 MAC addresses) |
| • Dynamic DNS |
| • DHCP Server and Client |
| • NAT (Network Address Translation) |
| • Bridging |
| • IP fragmentation and reassembly |
| • NTP (Network Time Protocol) |
| • Support for up to 253 client devices |
| • Quality of Service (QoS) support |
| • VPN pass through: PPTP, IP sec tunnel |
| • Parental Control |
| • Attack Protection |
| • Password protected system management |
| • IP/ MAC/Port filtering |
| • WPS(Wi-Fi Protected Setup) |
| •64/128-bit WEP, AES, TKIP, WPA, WPA2, WPA-PSK,
WPA2-PSK, WDS |
| 整机功耗 | Max.17W |
|---|
|
| 适用环境 |
|---|
| 工作温度 | 0℃ to 50℃ |
|---|
| 存储湿度 | -10℃ to 60℃ |
|---|
| 工作湿度 | 10% to 95% R.H |
|---|
|
